SWT-NS600B powerful metal hot wedge welder for waterproofing projects

Large Image : SWT-NS600B powerful metal hot wedge welder for waterproofing projects

Product Details:

Place of Origin:	CHINA
Brand Name:	MM-Tech
Certification:	CE
Model Number:	SWT-NS600B Extrusion Welder

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	$1500/set
Delivery Time:	7 work days
Payment Terms:	T/T
Supply Ability:	≤10sets——7days

Contact Now

Detailed Product Description

Model:	SWT-NS600B Extrusion Welder	Warranty:	2 Years
Welding Speed:	2.0kg/h	Thickness Of Material:	8-40mm
Weight:	6.5kg	Place Of Origin:	China
For Application Range:	Manufacturing Plant	Motor:	HITACHI

Introduction

This plastic extrusion welder is the first one in China that has functions of double independent heating systems, digital display

controller, 360 degree rotating welding head, motor cold start protection, which is applicable to welding PE,PP,PVC,PVDF and other

hot melt material.

Description of

Model	SWT-NS600B
Voltage	220V/110V
Frequency	50/60 Hz
Extruding Motor Power	3400 W
Hot Air Power	800 W
Welding Rod Heating Power	20-600 ℃
Air Temperature	200-380 ℃
Extruding Volume	2.0Kg/h
Welding Rod Diameter	3.0-4.0 mm
Driving Motor	HITACHI
N.W	6.5Kgs
G.W	13Kgs

Features

1. Double heating system: welding rod feed heating system and hot air heating system make sure the best welding quality. 2. Digital display controller microcomputer chip contoller makes easy operation. 3. 360 degree rotating welding head: the 360 degree rotating welding head: the 360 degree rotating hot air welding nozzle can be applied to different needs. 4. Motor cold start protection : extruding motor well shut down automatically if it has not reached the preset melting temperature, which avoid lose caused by operating mistake. 5. Driving motor: METABAO

Application

Operation Video

00:00

00:37

After-Sales Service


We always provide high quality products and workable price for every clients and have won the trust and approval.

Machine Quality Guarantee: 24 months.--If any parts broken or does not work under normal operating, we provide them for free.
