Product Details:
Payment & Shipping Terms:
|
| Product Name: | Automatic Butt Welding Machine | Weld Able Material: | PE,PP,PPR,PVDF |
|---|---|---|---|
| Working Range: | 280-500 | Power Supply: | 400V |
| Total Absorb: | 9.5KW | Warranty: | 24 Months |
| Weight: | 510KG | Usage: | Plastic Welding |
| Condition: | New | Frequency: | 50HZ/60HZ |
| Piston Area: | 23.06 | Type: | Welding Equipment,HDPE Pipes Butt Fusion Welding Machine,Hydraulic |
50 / 60 HZ 280 - 500 HZ Pipe Jointing Automatic Butt Welding Machines
Automatic Butt Welding Machine Introduction:
The MM-TECH V-CNC series automatic hydraulic butt welding machines are applied to joint PE, PP, PPR and PVDF pipes and moulded fittings.
Selection of components with a long service life ensures a low maintenance and repair, friendly and reliable operation.
Automatic Butt Fusion Welding Machine Specification:
| Welding Range | 280mm-500mm |
| Reducing Inserts | 280mm-315mm-355mm-400mm-450mm-500mm |
| Ranges of Application | PE,PP and PVDF |
| Working Voltage | 400V±10%,50/60Hz |
| Total Power | 9.5KW |
| Heating Plate | 6.5KW |
| Planning Tool | 1.5KW |
| Hydraulic Unit Motor | 1.5KW |
| Environment Temperature | -10°~45° |
Automatic Butt Fusion Welding Machine Features:
Safe, reliable and more powerful.
Rothenberger design patent for frame, ergonomic, robust and reliable.
Powerpac power control unit provides safety and stability.
Precise temperature control and small deviation on the heating plate surface to apply high welding standard.
Precise, reliable and powerful planing tools to ensure high welding quality.
Single inserts as the option to ensure higher connection allignment.
Removable PTFE coated heating plate with separate temperature control system.
Electic Planning tool with reversible double cutting edge blades.
Hydraulic unit provides welding machine with compressing power.
Be made of Aluminum material.
Low starting pressure ensures reliable welding quality of small pipes.
Temperature Controller and Timer ,easy to know the exact time and temperature .
SWT-V500A includes:
A machine body with 4 clamps and 1 automatic console with quick connector;
A Teflon coated heating plate with separate temperature control system;
Self detaching device: helps removing the heating plate after soaking process;
A electrical milling cutter;
Hydraulic hoses with quick couplings;
Support for milling cutter and heating plate.
Workshop:
FAQ:
Q1: Are you manufacturer or trading company?
A: We are Manufacturer with more than 10 years foreign trade experience. We have our own factory.
Q2: Can you produce based on our drawing & sample? We may also need our logo on it.
A: Yes, of course. We do OEM & ODM services. And definitely you can have logo on it.
Q3: What is the delivery time for bulk production?
A: About 30 days.
Q4: What about payment?
A: Usually we may ask for 30% T/T deposit and 70% T/T balance at the sight of B/L copy.
Q5: How do you control quality?
A: Under management of ISO9001 system, we check every process of production.
